    100T Heavy Duty Crimp Cable Press Fit Tool / Split Type Hydraulic Crimping Pliers

    Ask Lasest Price
    Brand Name : Newart
    Model Number : LD7630P
    Certification : ISO
    Price : Negotiable
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 per month
    Delivery Time : 15days after Payment
    • Product Details
    • Company Profile

    100T Heavy Duty Crimp Cable Press Fit Tool / Split Type Hydraulic Crimping Pliers

    YJD-1000 100T Heavy Duty Crimp Cable Press-fit Tool Split-type Hydraulic Crimping Pliers


    Heavy Duty Crimp Cable Description


    Split hydraulic crimping head can work with hydraulic pump

    It is suit for crimping big size of lugs

    It is suitable for outside and inside project of the distributor,it is the special tools for all kinds if connecting and building over head cable


    Heavy Duty Crimp Cable Feature


    1. It is suitable for outside and inside project of the distributor house, it is the special tools for all kinds of the connecting and building over head cable.

    2. It pressed tightly on 10kv-500kv high voltage cable casing pipe, clips nared ends and hexagon shape.

    3. The oil pipe coipler fitted with PT 3/8'' thread.

    4.To be worked with pedal pump, manual pump and electric driven hydraulic pump.


    Heavy Duty Crimp Cable Technical Data


    Item number1610316103A161041610516106
    ModelYJD-600YJD-1000YJD-1250YJD-2000YJD-3000

    Crimping

    force

    60T100T125T200T300T

    Crimping

    range

    14-55mm14-76mm14-76mm14-90mm14-100mm
    typehexagon crimpinghexagon crimping
    Stroke24mm24mm35mm35mm

    Heigth

    approx.370mmapprox.480mm

    Weight

    (KG)

    approx.N.W20KG

    G.W30KG

    approx.N.W30KG

    G.W40KG

    approx.N.W50KG

    G.W60KG

    approx.N.W85KG

    G.W95KG

    approx.N.W120KG

    G.W130KG

    Packagewooden casewooden case

    Details
